Toshiba e-Studio

Toshiba’s high-end A3 colour MFP is as impressive on the outside as it is on the inside. Its ultra-modern look houses the latest innovative technology, like brilliant quality delivered at up to 55 pages per minute in colour and 65 pages per minute in monochrome.

Download Brochure Make an Enquiry Contact us


Features of the Toshiba e-Studio

GENERAL (image shown with optional specs)

Control Panel
10.1” Colour WVGA Touch Screen Tilting Display
Dimensions & Weight
955 x 698 x 1,227 mm (W x D x H), 213 kg
Paper Size & Weight
Cassettes: A5R-320 x 460 mm, 60-256 gsm. Tandem LCF*: A4, 60-256 gsm. Bypass: 100 x 148 mm-330 x 483 mm, 60-300 gsm, banner paper (up to 313.4 x 1,200 mm, 90-163 gsm)
Controller Type
Toshiba e-BRIDGE Next
Warm-up Time
Approx. 15 Seconds from low power mode
Paper Capacity
2x 540 sheets. (Cassettes) + 1x 2,320 sheets (Tandem LCF)*, 1x 120 sheets (Bypass). Maximum 6,020 sheets
Memory
Toshiba Secure HDD 320 GB**, 4 GB RAM
Print Speed
Colour: 55 ppm (A4), Mono: 65 ppm (A4)
Automatic Duplex
A5R-320 x 460 mm, 60-256 gsm
Interface
10Base-T/100Base-TX/1000Base-T, High Speed USB 2.0, WLAN*** (IEEE802.11b/g/n), Bluetooth***, Wi-Fi Direct***

PRINT

Resolution
600 x 600 dpi, 1,200 x 1,200 dpi (2 bit, PostScript driver only), 3,600 x 1,200 dpi with smoothing (PostScript driver only, monochrome)
Page Description Languages
PCL5e, PCL5c, PCL6 (PCL XL), XPS and PostScript 3 compatible
Print Functions
Universal Printer Driver, Driver Templates, Driver plug-ins*, Print from USB, Hold print, Tandem printing
Supported Systems
Windows 10/8/7/Vista/Server 2008 (32/64 bit), Windows Server 2012/Server 2008 R2 (64 bit), Mac OS X 10.6.8-10.11, Linux/Unix, Citrix, Novell NetWare (NDPS), SAP, AS/400

SCAN

Scan Functions
WS Scan, Scan to USB, Scan to E-Mail, Scan to File (SMB, FTP, FTPS, IPX/SPX, Local), Meta Scan***, OCR scan***, Scan to Box (e-Filing), WIA, TWAIN
Resolution
600 dpi, 400 dpi, 300 dpi, 200 dpi, 150 dpi, 100 dpi
Scan Speed
up to 240 ipm (300 dpi) in colour and monochrome via Dual Scan Document Feeder
Scan Modes
Auto-Colour (ACS), Colour, Greyscale, Monochrome
File Formats
JPEG, Multi/Single Page TIFF/XPS/PDF, Secure PDF, Slim PDF, PDF/A, PDF/A-2, Searchable PDF*** (and other formats like DOCX, XLSX)***

FAX (optional)

Transmission Speed
Approx. 3 seconds per page
Incoming Fax Routing
To shared folders (SMB, FTP, IPX/SPX), E-Mail, e-Filing
Communication
Super G3, G3 - (opt. 2nd line)
Network Fax
Driver for Windows 10/8/7/Vista/Server 2008 (32/64 bit), Server 2012/Server 2008 R2 (64 bit)
Compression
MH/MR/MMR/JBIG

COPY

Resolution
Scan: 600 x 600 dpi Print: 600 x 600 dpi, 2,400 x 600 dpi with smoothing
Colour Modes
Auto-Colour (ACS), Full Colour, Twin Colour, Mono Colour, Monochrome
First Copy Output Time
Colour: Approx. 6.4 seconds. Monochrome: Approx. 5.2 seconds
Colour Settings
Hue, Saturation, Colour Balance, RGB adjustment, 5 one-touch modes
Zoom
25-400% (Platen), 25-200% (DSDF)
Copy Modes
Text, Text/Photo, Photo, Printed Image, Map, Image Smoothing
Copy Functions
Electronic Sort, Rotate Sort, ID Card Copy, Edge Erase, 2-in-1 / 4-in-1 mode
[This Class 1 laser product complies with IEC60825-1]. Technical data is subject to change without prior notice. All company and/or product names are trademarks and/or registered trademarks of their respective manufacturers in their markets and/or countries. All rights reserved. We are constantly making efforts to deliver the latest status of data to our partners. Specifications for some models may change in the time between the production and the release of this documentation. Productivity and paper specifications are related to paper size of A4 and a paper weight of 80 g/m2 if not otherwise mentioned. Warm-up time and print speed may vary depending on the operating environment.

1 GB = 1 billion bytes; the actual formatted capacity is less. Available capacity will also be less if software applications are pre-installed.

* Optional

Copyright ©2018 TOSHIBA TEC.

Enquire about the Toshiba e-Studio

Optional Extras:

More about the Toshiba e-Studio

CONNECT. INTEGRATE. SIMPLIFY.

ADVANCED E-BRIDGE NEXT TECHNOLOGY

Toshiba’s next-generation e-BRIDGE architecture features an embedded web browser, 4 GB RAM and the Toshiba secure hard disk drive enabling the MFP to easily drive Toshiba’s internally developed solutions or even third-party applications.

Create a lasting impression with high-quality document output in colour and monochrome with a resolution of up to 1200 dpi x 1200 dpi.
A simple touch of a button is all it takes to start an automated workflow powered by the optional dual scan document feeder.

COMPACT STYLISH AND FULLY CUSTOMISABLE

A large touch screen is your gateway to document handling which has never been easier. Size and order of icons as well as the background image can be customised. Enjoy the unique experience of working with a system that understands what you want.

COMPLETE PEACE OF MIND

Toshiba keeps the security of your business top of mind. Like a self-encrypting Toshiba Secure HDD that provides top level security. You can also add optional security functions to make the system compliant with IEEE2600.1 and meet the EAL3 Common Criteria requirements. IPsec is also available to securely encrypt data sent to and from the MFP.

SEAMLESS CONNECTIVITY TO INDUSTRY STANDARD APPLICATIONS

The optional e-BRIDGE Plus connectors for Microsoft OneDrive, Google Drive and Dropbox let you send your documents directly to or print from these cloud services via the MFP.

BUILT IN CONVENIENCE

This MFD has been designed to accommodate a range of optional card readers, not only provides fast and convenient access to your print jobs but also increases data security.

RESPONSIBILITY FOR THE PLANET

Innovation ensures that our environment is part of the equation, which is precisely what we do at Toshiba. This state-of-the-art MFP is RoHS compliant and uses recycled plastics and a low-power Super Sleep Mode to save resources
